Hardware Interface

MCP Software how-to

An APP by name of MCP works as the main program in this android system based body camera, pls try it free with VMS as device simulator.

it has below functions,

encoder+live streaming push to VMS/smarteye, including recording,live streaming, GPS tracking, 2-way audio , alarm report and snapshot. This part of work is called MPU

groupPTT/PoC

mobileClient(pull stream+decoder) + privateIM(like wechat)

e-map to locate other units

playback

typical MCP howto, https://www.besovideo.com/en/detail?t=1&i=126



for details pls refer to “MCP user manual” for detailes.





VMS/smarteye software

about smarteye C/S client monitor&manager, https://www.besovideo.com/en/detail?t=1&i=87

FAQ for server-E WEB software, https://www.besovideo.com/en/detail?t=1&i=166



access recording footage files in the camera

connect the body camera to a WINDOWS PC via USB cable,  it works as a U-disk.

 the internal storage(TF card) can be accessed, read/write/delete enabled. video footage files are in MCU/video  path.



for more about about recording in mobile CCTV solutions, pls refer to   https://www.besovideo.com/en/detail?t=1&i=146
